Diverters

Mipra Steel is one of the most leading Pipe Fitting mild steel Diverters fittings Manufacturer, STOCKIST and SUPPLIERS in Maharashtra , Chhattisgarh , Kerala , Telangana , Gujarat ,Rajasthan , Madhya Pradesh , Uttar Pradesh , Tamil Nadu ,Kolkata,Karnataka India.
We Also Export International China,Canada,Mexico,Japan,Germany,Italy,Brazil,Dubai,Saudi etc. .

Our Tee and Wye dampers are designed to give long, trouble free service in all low pressure service applications. The versatility of the fabricated Tee and Damper allows to design to your specifications as required by your systems.

Sizes up to 96″ (Larger and special sizes consult for quote)
Flanges, Body & Disc: Standard – Carbon Steel, Optional – Corten, Aluminum, Stainless (All 300 Series), Carpenter 20, Titanium, Tantalum, Refractory Lined Body
Shaft: Standard – 304 SS, Optional – Aluminum, Aluminum -Br, Stainless (All 300 Series), Carpenter 20, Titanium, Tantalum
Bushings: Standard – Carbon (3000°F), Optional – Gr. Br. Stainless (All 300 Series), Stellite, TFE, Glass Filled TFE
Bearings (Outboard ball): Standard – 72″ & above (Std. w/ seat), Optional – Ball & roller (all sizes)
Packing Follower: Standard – 304, Optional – Same alloys as body
Lantern Gland: Standard – Carbon, Optional – Same alloys as body
Seat: Standard – Swing-through, Optional – Scissor, Metal & Tadpole
Maximum Operating Temperature: Standard 750°F, Optional 2100°F
Maximum Static Pressure: Standard 5 PSIG, Optional 150 PSIG
Maximum Shut-Off Pressure Drop: Standard 1 PSI, Optional 50 PSI
ANSI drilled flanges with various thicknesses available.
Outboard bearing on blind end available.
Flange thickness based on size and service.
Rolled angle flanges available on medium duty low temperature, low pressure applications.
Flanged or weld ends.
